SD-A5 Square Ceiling Diffuser,air conditioning diffuser size,Curved blade square air diffuser

SD-A5 Square Ceiling Diffuser Core can be easily removable and interchangeable to allow for maximum flexibility in the installation, maintenance, and damper adjustment

Product Specification:

  • Place of Origin :

    Guangdong, China (Mainland)

  • Model Number :

    SD-A5

  • Type :

    HVAC Systems

  • Material :

    Extruded Aluminum Alloy (Minimum 1.0mm Thickness)

  • Surface Finish :

    Powder coated / Anodized

  • Standard Color :

    RAL9016,9010

  • OEM Service :

    Available

  • Customer's logo :

    Available

Inquiry Now
May you like

Construction:

  • Frame: High quality extruded aluminum alloy(A6063) profile with 79.0mm flange width
  • Core: High quality extruded aluminum alloy(A6063) profile in 38.4 degree

Description:

  • The frame & blades are high quality extruded aluminum profiled construction with advantages of corrosion resistance and rigidity.
  • Lourvered type core is fixed to the frame with aluminum pins loaded with steel springs. Core can be easily removable and interchangeable to allow for maximum flexibility in the installation, maintenance and damper adjustment.

Details:

  1. Surface Finish: Powder coated color finish as per RAL color----standard color: RAL9016, 9010;  Natural anodized aluminum finish
  2. Material thickness: 1.0mm
  3. Accessory: OBD, Neck adaptor

Size:

  • Any size available
  • Overall face size = Neck size +225mm=A+225mm

Standard size

Item Code

Neck Size(mm)

Face Size(mm)

SD-A5-150

150x150

600x600

SD-A5-225

225x225

600x600

SD-A5-300

300x300

600x600

SD-A5-375

375x375

600x600
