SDG-A1 Air condtioning adjustable air grille, supply air grille, single deflection air grille - Aluminum air diffuser & grille
SDG-A1 Air condtioning adjustable air...

Morbi accumsan ipsum velit. Nam nec tellus a odio tincidunt auctor a ornare odio. Sed non mauris vitae erat consequat auctor eu in elit.

Product Specification:
  • Place of Origin :

    Guangdong, China (Mainland)

  • Model Number :

    SDG-A1

  • Type :

    HVAC Systems

  • Material :

    Extruded Aluminum Alloy (Minimum 1.0mm Thickness)

  • Surface Finish :

    Powder coated / Anodized

  • Standard Color :

    RAL9016,9010

  • OEM Service :

    Available

  • Customer's logo :

    Available

Construction:

  • Frame: High quality extruded aluminum alloy(A6063) profile with 30mm flange
  • Blade: Aerofoil blades from aluminum profile
  • Blade spacing: 20mm as standard

Description:

  • The frame & blades are high quality extruded aluminum profiled construction with advantages of corrosion resistance and rigidity.
  • Both vertical blades and horizontal blades are available, SG-AV: vertical blades, SG-AH: horizontal blades
  • Blades can be adjusted mannually and individually to provide air deflection in both horizontal and vertical planes.
  • Maximum affective pressure areas can be achieved when the blades are positioned at 0 degree.

Details:

  1. Surface Finish: Powder coated color finish as per RAL color----standard color: RAL9016, 9010, Natural anodized aluminum finish
  2. Material thickness: 0.8mm, 1.0mm, 1.2mm for option
  3. Accessory: OBD, Neck adaptor

Size:

  • Any size available
  • Overall face size = Neck size +55mm

Standard size:

W×H

mm×mm

W×H

mm×mm

W×H

mm×mm

W×H

mm×mm

W×H

mm×mm

150×150 300×200 400×150 500×150 650×100
200×100 300×250 400×200 500×200 700×250
200×125 300×300 400×250 500×250 750×100
200×150 350×125 400×300 500×300 750×150
250×100 350×150 400×400 500×350 750×200
250×125 350×200 450×100 500×400 750×250
250×150 350×250 450×150 600×125 900×150
250×200 350×300 450×200 600×150 900×200
250×250 350×350 450×450 600×200 1000×200
300×100 400×100 500×100 600×250 1200×150
300×125 400×125 500×125 600×300
