Product Specification:
  • Place of Origin :

    Guangdong, China (Mainland)

  • Model Number :

    SG-LR

  • Type :

    HVAC Systems

  • Material :

    Extruded Aluminum Alloy (Minimum 1.0mm Thickness)

  • Surface Finish :

    Powder coated / Anodized

  • Standard Color :

    RAL9016,9010

  • OEM Service :

    Available

  • Customer's logo :

    Available

Construction:

  • Frame: High quality extruded aluminum alloy(A6063) profile with 30mm flange as standard.
  • Blades: Aerofoil blades in 45° from aluminum profile
  • Blades spacing: 25mm as standard
  • Support pipe: 8mm diameter aluminum pipe
  • Round shape

Description:

  • The frame & blades are high quality extruded aluminum profiled construction with advantages of corrosion resistance and rigidity.
  • The blades is fixed to the frame by rivets and support pipe, which assure the quite, smooth and rattle free operation.
  • Blades are set at angle of 45° with 25mm spacing, and fixed to the frame.

Details:

  1. Surface Finish: Powder coated color finish as per RAL color----standard color: RAL9016, 9010, Natural anodized aluminum finish
  2. Material thickness: 0.8mm, 1.0mm, 1.2mm for option
  3. Accessory: Air Filter, OBD(Opposed Blade Damper

Size:

  • Any size available
  • Overall face size = Neck size + 55mm

Standard size (Neck size=A):

Item

Neck size (mm)

Face size (mm)

SG-LR-100

D100

D160

SG-LR-150

D150

D210

SG-LR-200

D200

D260

SG-LR-250

D250

D310

SG-LR-300

D300

D360

SG-LR-350

D350

D410

SG-LR-400

D400

D460
